Texmate Panel Meter BN-35



BN-35

Base Price $149.00

The BN-35 is pin to pin compatible with the Newport model 215. The BN-35 is a low cost pin for pin functional replacement for the Newport model 215, with many more features. It is a 3 1/2 digit voltmeter in a compact 96x24mm DIN case with non-isolated 5VDC power. Another version of the BN-35, the BN-35I with in- ternally isolated 9V, 12V, 15V or 24VDC power, is also available. The case has a short depth of just 2.83 inches (72mm) behind the panel. The meter has four user-selectable ranges of 200mV, 2V, 20V and 200V. The BN-35 may also be calibrated at the factory for these ranges or specially scaled for other ranges (see Ordering Information below). Provision to offset the zero is also available as an option for 4-20mA signals. The DIN case is interchangeable with all Texmate meters of a similar form factor. Replacements or repairs are "plug-and-play".

Features & Specifications

Download BN-35 Features & Specifications (PDF).

Download Newport's 215 and Texmate's BN-35 Features Comparison Table.

Product Information

Download BN-35 Full Manual (PDF).


Custom Faceplates and Labels for Meters

Artwork Data Recovery Fee

Custom Legend on non-membrane type faceplate

Up to four characters on non-membrane type faceplate

Display Custom Scaling

Qty Custom display scaling within standard ranges

Engineering Services

$ Qty

External Decimal Selection Board

3.5 digit, Super Bright Red LED
3.5 digit, Green LED display

Range Change

Factory calibrated range change, see specific meter's data sheet.
Zero offset 50 K Pot.
BN-35 and BN-35I only, 200 mV, 200 V or 200 VDC Range Change.
Non-standard Range and Scale changes.

Small Run Custom Faceplates for Meters and Bargraphs

Produce and install custom faceplate per meter - 1 color
Produce and install custom faceplate per meter - 2 color
Produce and install custom faceplate per meter - 4 color
NRC for Artwork & set-up Custom Faceplate and/or Descriptor

4" Switchboard Panel Mounting Adapter Plate

Cases and Case Accessories

Connectors

Power Supply
