A powerful, intelligent, 5/6-digit Programmable Meter Controller (PMC) with modular input signal conditioning Modules and various outputs, advanced software features for monitoring, measurement, control and communication applications.

Software:
• The Tiger 320 Operating System supports an easy to use PC based Configuration Utility Program (which can be downloaded FREE from the Texmate website) and programming via front panel buttons.
• Cross channel math functions to calculate the sum, difference, ratio or the product of two inputs.
• Brightness control of LED display from front panel buttons.
• On demand tare, calibration and compensation can be initiated by the front panel program button.
• Autozero maintenance for super stable zero reading is provided for use in weighing applications.
• Programmable input averaging and smart digital filtering for quick response to input signal changes.
• Display text editing. Customize display text for OEM applications.
• Dual independent totalizers to integrate input signals.
• 6 super smart, independently programmable setpoints with 8 selectable functions, including latching, deviation, hysteresis, register resetting, tracking and dual PID. Plus 7 programmable timer modes on all 6 setpoints.
• Setpoints activated from any input, any register in the meter or from any digital input.
• Peak & valley (max & min) with front panel recall and reset.
• Up to 4 selectable 32 point or one 125 point flexible linearization tables are provided.
• Logging with a date/time stamp, initiated at timed intervals, by activation of a setpoint, or manually.
• Free Tiger Apps Development System to create powerful customization to suit any proprietary OEM application.

Hardware:
• The Tiger Controller with it's modular construction simplifies the use for any control and measurement needs.
• More than 120 different interchangeable input signal conditioning module, from 4-20mA, 5AAC, AC Volts, Thermocouple, RTD, Load Cell, Quad Thermocouple, 4-20mA, RTD or combination of RTD+4-20mA, T/C+4-20mA, ACV/AC Amps=Watts and more.
• Different type of Displays are available. 5digit, 6digit, Dual 6digit, Triple 5digit, Bargraph, LCD 6digit and more.
• Auto-sensing high voltage (85-265 VAC / 95-300VDC) or optional low voltage(15-48VAC/10-72VDC) AC / DC power supply.
• Serial output options include RS-232, RS-485, ModBus, Ethernet, or direct meter-to-meter communications.
• Single or dual 16-bit Isolated Analog Outputs. Programmable 0~4 to 20mA or 0 to 10V for retransmission, 4-20mA loops to drive valve actuators, remote controllers & displays, multi-loop feedback and PID output. Scalable from 1 count to full scale.
• For applications where sensor excitation is required, modules are provided with 5V, 10V or 24 V DC voltage outputs.
• Plug-in I/O modules include electromechanical or solid state relays, logic outputs or open collector outputs. 6 inputs & 16 outputs of opto-isolated I/O can be connected to an external DIN Rail terminal block module.
• Internal program safety lockout switch to prevent tampering.
• Data logging in internal 1MB EEPROM or in a removable SD Card Memory Module.
• Real time clock with 15 year Lithium battery backup.
• Optional NEMA-4 front cover.
• UL Listed
• CE Certified



E Version and T Version (Macro Enabled for Autonomous Custom Applications)

DI-50E
DI-50E
DI-50T
DI-45U (discontinued)
DI-50D (discontinued)

Function Dedicated Tiger Meters

BDD-652
BDD-652
Magnetostrictive Start/Stop Controller

DI-50-FLOW
DI-50-FLOW
Flow / Rate Totalizer

DI-50-MS
DI-50-MS
Manual Auto Station

DI-50-MAS1
DI-50-MAS1
Manual Auto Station

DI-50-MAS2
DI-50-MAS2
Manual Auto Station

DI-503MAS
DI-503MAS
Manual Auto Station

DI-602MAS
DI-602MAS
Manual Auto Station

DI-50-POWER
DI-50-POWER
Power / Energy
Programmable Meter Controller (PMC)

DI-503-POWER
DI-503-POWER
Power / Energy
Programmable Meter Controller (PMC)

DI-50E-PROCESS
DI-50E-PROCESS
Process
Programmable Meter Controller (PMC)

FI-BD-MAS
FI-BD-MAS
Manual Auto Station

LVDT-100
LVDT-100
Positioning, Displacement Controller

LVDT-200
LVDT-200
Positioning, Displacement Controller

SG-100
SG-100
Weighing, Load Cell Controller

TD5300
TD5300
Magnetostrictive Start/Stop Controller

DIN Rail Mount Micro PLC /Controllers /Transmitters- Versatile Custom Configuration

The TI series is Tiger equivalent. It includes the same 130+ input signal conditioner options, up to six relay outputs or 16 digital outputs, one or two-channel analog outputs (4-20mA or 0-10VDC), and RS-485/Ethernet (ASCII or Modbus) communication options.

It is suitable for power/energy (single-phase), volts, amps, process inputs, weighing, batch, displacement, and many other applications that take advantage of advanced functions such as dual totalizers, 32point input linearization, dual PID, cross channel math and IIoT readiness (Edge computing capable using TexBASIC).

TI-500
TI-500
DIN Rail Mount
6 Setpoints Micro PLC

TI-501
TI-501
DIN Rail Mount
5 digit (99999) display
6 Setpoints Micro PLC

TI-502
TI-502
DIN Rail Mount
2 x 5 digit (99999) display
6 Setpoints Micro PLC

TI-503
TI-503
DIN Rail Mount
3 x 5 digit (99999) display
6 Setpoints Micro PLC
